Description
Intermatic 300 Watt Transformer PX300
Intermatic Safety Transformers are specifically designed to supply 12 volts to pool and spa lights, submersible fixtures and outdoor garden lights. A grounded shield between the primary and secondary windings assures safe operation and the built-in circuit protection will disconnect power to the transformer in case of defect or overload.
The 300 Watt Transformer can operate up to 20 Pentair Landscape Lights or up to 6 LED Swimming Pool Lights.
PX300 Transformer Features:
Intermatic PX300
Intermatic Safety Transformers are specifically designed to supply 12 volts to pool and spa lights, submersible fixtures and outdoor garden lights. A grounded shield between the primary and secondary windings assures safe operation and the built-in circuit protection will disconnect power to the transformer in case of defect or overload.
The 300 Watt Transformer can operate up to 20 Pentair Landscape Lights or up to 6 LED Swimming Pool Lights.
PX300 Transformer Features:
- Stainless Steel Enclosure with light beige finish and mounting brackets at the top and bottom.
- Total of 10 combination 1/2" - 3/4" knockouts, (2) Right Side, (2) Left Side, (2) Back and (4) on Bottom.
- Withstands harsh environments such as high heat, humidity and chemicals.
- Input: 120 VAC, 3 Amp
- Output: 12, 13 or 14 Volt
- CSA C/US Listed
- 7-1/4" Height X 5-1/2" Width X 4-1/2" Depth
Intermatic PX300
